Slurry Seal-ZR30051UP IMS

Slurry Seal-ZR30051UP IMS has been specially designed to handle abrasive substances that are maximum 30% of its weight. This seal is used for non metallic pumping system ( for PFA/PVDF lined pump). It is fitted for impeller and back plate of pumping system to avoid leakage. Offered seal comprises of helical pumping ring, seal face with hydraulically balancing mechanism and coated spring. Advanced design of this pump seal promotes better siphoning effect.  Slurry seal can be operated at maximum 8 bar of operating pressure and at maximum 180 degree C operating temperature.

Material

• Seal Ring Faces : SiC and Carbon
• Seat Faces :SiC
• Elastomer : Viton, TTV, FEP and FFKM
• MOC : SS 316, PVDF  CHANGE OF MOC ON REQUEST

• Shaft Dia. : 20mm to 80mm
• Pressure : Upto 8 bar
• Temperature :  Upto 180 degree C
• Speed: 3000 r.p.m.
